Details

DIMENSIONS:(mm)

FEATURES

· Ultra thin design, easy integrate into environment

· High CRI and no glare flat lighitng

· Easy installation, plug and fast connection

· Silver and black color frname available

· Normal color and CCT available

· For surface mounting-screw fixing

· Material: plastic

· IR switch available

STANDARDS

EN 60598-1 EN 55015

CHARACTERISTICS
RATED INPUT VOLTAGE: DC12V/24V (power factor measured at DC12V/24V and full load)

Model No.	Input Voltage	Power	Lumen	Color Temperature	L×W×H	Approval
BHLL-208M	DC12V	25W	180lm	2700K/3000K/4000K/6500K	16×8×208mm
BHLL-408M	DC12V	5.52W	350lm	2700K/3000K/4000K/6500K	16×8×408mm
BHLL-508M	DC12V	6.71W	420lm	2700K/3000K/4000K/6500K	16×8×508mm
BHLL-708M	DC12V	8.8W	540lm	2700K/3000K/4000K/6500K	16×8×708mm
